TECHNICAL SPECIFICATIONS
Engine
Type Air-cooled, 4-stroke single cylinder OHC
Displacement 97.2 cc
Max. Power 5.74 KW (7.8 Ps) @ 7500 rpm
Max. Torque 8.04 N-m @ 4500 RPM
Bore x Stroke 50.0 x 49.5 mm
Carburettor Side draft, variable venturi
Compression Ratio 9.0 : 1
Starting Kick Start/ Electric- start
Ignition DC CDI with TCIS
Transmission & Frame
Clutch Multiplate-wet
Gear box 4 Speed constant mesh
Frame Type Tubular double cradle frame
Suspension
Front Telescopic hydraulic shock absorbers
Rear swing arm with 5 step adjustable hydraulic shock absorber
Brakes
Front Brake Internal expanding shoe type (130 mm) type
Rear Brake Disc Internal expanding shoe type (130 mm) type
Wheels & Tyres
Rim Size Front 18 x 1.60, Spoke wheel / Cast wheel (optional)
Rim Size Rear 18 x 1.60, Spoke wheel / Cast wheel (optional)
Tyre Size Front 2.75 x 18 – 42 P / 4 PR
Tyre Size Rear 2.75 x 18 - 48 P / 6 PR
Electricals
Battery MF battery, 12V 3Ah (Kick), 12 V4 Ah (Electric)
Head Lamp 12V - 35W / 35W - Halogen bulb (Multi focal reflector)
Tail/Stop Lamp 12 V - 5 /10W (Multi-Reflector Type)
Dimensions
Length 1970 mm
Width 720 mm
Height
1040 mm
Saddle Height
785 mm
Wheelbase
1230 mm
Ground Clearance
159mm
Fuel Tank Capacity
11 ltrs (Min).
Reserve
1.4 Litre (Usable reserve)
Kerb Weight
109 kg, (Kick), 112 kg (Self)
Information source www.heromotocorp.com on 2014.12.27
